LE9 Lower OP Panel - Removable Trackball Hirose Compatible

5207000-92
5207000-82
Ultrasound
Other Ultrasound
GE Healthcare
Add to Wish List
Sign In & Add To Cart
Sign In & Add To Cart
Please select date
Second Opinion Approval Needed

Enter your approval number and submit to add item(s) to cart.

Approval Number

Please enter approval number

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.

Second Opinion Approval Needed

Select your approver's name and submit to add item(s) to your cart

Approver Name

Please Select Approver Name

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without
selecting an approver, GE will contact you before your order
can be confirmed for shipment.


Product Overview

The LE9 Lower OP Panel - Removable Trackball Hirose Compatible is an operator panel that is a complex user interaction device with several sub devices. This lower operator panel is equipped in LOGIQ E9. The operator panel includes a trackball with buttons, an alphanumeric keyboard, and a custom keyboard. The operator panel will be used on Ichiro and LOGIQ E9, a medical diagnostic ultrasound imaging system. The lower operator panel is installed into a plastic frame with integrated handles and probe holders with the help of eight screws. The host will communicate with the Operator Panel (OP) through USB. There are two USB connections, one for the video and another for the rest of the OP devices. The operator panel contains functional user controls like a custom keyboard (keys, encoders, slide pots and illuminated indicators), QWERTY keyboard (with backlighting), trackball, auxiliary USB ports accessible the operator (2) and auxiliary USB ports accessible the operator (2). This lower operator panel is compatible with the removal of the trackball with the Hirose connector, the alphanumerical keyboard is removable from the topside of the operator panel. The system operator panel can be freely moved in all directions. It can be controlled both automatically and manually. The LOGIQ E9 is equipped with an automatic operator panel up/down, left/right, forward/backward control. If the system is powered down when you need to lower the operator panel, one can use the manual release handle located at the back of the unit to manually move the operator panel up/down.

Equivalent Part

Below is more information on the equivalent parts. Parts without a hyperlink are listed for reference only and are not available for purchase online.

Equivalent partPart Details
5207000-82 LE9 Lower Op Panel - removable trackball compatible
