Assembly Mother Board Flex with CPU with 1GB SDRAM 2 DVI

2051751-005
2051751-001
Diagnostic ECG
Stress ECG
GE Healthcare
Add to Wish List
Sign In & Add To Cart
Sign In & Add To Cart
Please select date
Second Opinion Approval Needed

Enter your approval number and submit to add item(s) to cart.

Approval Number

Please enter approval number

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.

Second Opinion Approval Needed

Select your approver's name and submit to add item(s) to your cart

Approver Name

Please Select Approver Name

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without
selecting an approver, GE will contact you before your order
can be confirmed for shipment.


Product Overview

The Assembly Mother Board Flex with CPU with 1 GB SDRAM 2 DVI in Diagnostic ECG is used in Stress and other medical equipments as applicable. The flex board is designed to be supplied from a standard ATX (or BTX) power supply or by single +12V. Use of BTX supply is not required for operation, but may be required to drive high-power cards. The keyboard or PS/2 mouse adapter is done through the stacked PS/2 mouse and keyboard connector. The PS/2 mouse and keyboard are supplied from SB5V when in standby mode in order to enable the keyboard or mouse activity to bring the system out from power saving states. The supply is provided through a 1.1A resettable fuse. The board have an integrated SATA Host controller that supports independent DMA operation on four ports and data transfer rates of up to 3.0 Gb/s (300 MB/s). The SATA controller supports AHCI mode and has integrated RAID functionality with support for RAID modes 0 and 1. The board contains two enhanced host controller interface (EHCI) host controllers that support USB 2.0 allowing data transfers up to 480Mb/s. The motherboard comes with the bios. The assembly is packed in an antistatic bag to avoid damage during shipping.

Compatible Products

CASE

CASE

Equivalent Part

Below is more information on the equivalent parts. Parts without a hyperlink are listed for reference only and are not available for purchase online.

Equivalent partPart Details
2051751-001 ASSY MB FLEX W/CPU SDRAM 2DVI
